D-Smart
(Standard Efficiency Model)
MODEL:
CAPACITY:
REFRIGERANT:
FTKQ-TVM
0.8 HP / 1.0 HP / 1.5 HP / 2.0 HP / 2.5 HP
R32
Daikin’s Inverter Technology provides the ideal temperature while using electricity efficiently and the Super PCB allows your air conditioner to withstand unstable voltage to prevent damage. Stay comfortable while maintaining your peace of mind.
Mindful of the environment and climate impact of its products, Daikin has taken the lead when it comes to shifting to refrigerants with a lower environmental impact.
Indoor Unit Quiet Operation
Enjoy quiet time with this feature as the indoor unit operating sound pressure levels will be lower than the Low setting fan speed.
Features
Odor Removal & Mold-proof Air Filter
Avoid mould with this feature as the fan-only operation runs automatically for one hour after the cooling or dry operation is stopped to dry the internal indoor unit and reduce the generation of mould and odours. This feature can also be operated manually.
Econo Mode
Energy efficiency is priority. In this mode, your air-con will only run on 70% of its actual capacity. If you want to keep your electricity bills low, this would be the best mode to use. This mode also prevents excessive cooling.
Comfort Airflow Mode
Avoid uncomfortable drafts with this feature by moving the flap upward during cooling operation and downward during heating operation.
✓ Withstands Low & High Voltages from 0 up to 440V
✓ Protects your investment
✓ Ensures the safety of electrical parts
✓ 3 years warranty for Outdoor PCB
✓ 1 year warranty for parts & labor
✓ 5 years warranty for compressor
Unstable power supply is a common problem in many parts of the world. It is well known for causing overvoltage, which can seriously damage electronic devices. However, it also causes undervoltage, which can shut down your air conditioner just when you need it the most.
Daikin’s printed circuit boards (PCB) are specially strengthened to withstand voltage fluctuations. This allows them to operate across a wide range of voltages in areas with unstable power. That is why Daikin offers you our new room air conditioning line-up that can withstand zero up to 440V.
Reminder:
When the voltage is higher or lower than the operating range, the air conditioning system automatically switches off. When the voltage is adjusted back to 220V, the air conditioning system automatically starts operating again.
Technical Specifications
Temperature Control by Inverter and Non-Inverter Compressors (Cooling)
MODEL NAME Indoor Unit | Cooling Capacity | Power Consumption | Dimensions (HxWxD) | Refrigerant | CSPF Rating | Energy Label QR |
|---|---|---|---|---|---|---|
FTKQ20TVM | 0.8 HP | 510W | 285mm x 770mm x 223mm | R32 | 5.20 (5★) | |
FTKQ25TVM | 1.0 HP | 810W | 285mm x 770mm x 223mm | R32 | 5.16 (5★) | |
FTKQ35TVM | 1.5 HP | 1200W | 285mm x 770mm x 223mm | R32 | 5.13 (5★) | |
FTKQ50TVM | 2.0 HP | 1730W | 285mm x 770mm x 223mm | R32 | 4.50 (5★) | |
FTKQ60TVM | 2.5 HP | 2210W | 285mm x 770mm x 223mm | R32 | 4.78 (5★) |
